Large diameter double row self—aligning roller bearings are adopted for main bearing instead of the original sliding bearing, reducing the friction and energy consumption, and making the mill start up easily.
It maintains the end cover structure of common mill, with large—caliber feeding and discharging openings, which realizes large processing capacity.
While making selection,the customer should specify the rotating direction and discharging mode of the ball mill.
Model Standards Revoluiion ofthe shell(r/min) Weight with balls (t) Size ofsupplyingminerals(mm) Output(t/h) Cooperate Motor Dimension(mm)(L× W×H) Weight(kg) Model Power(kW) MQG(Y)0912 ф 900×1200 41.6 1.1 ≤20 0.3〜0.9 Y180L-8 11 3843×1850×1400 4210 MQG(Y)0921 ф 900×2100 41.6 1.8 ≤20 0.6〜1.5 Y180L-6 15 4743×1850×1400 6660 MQG(Y)0933 ф 900×3300 41.6 2.8 ≤20 0.9〜2.3 Y225M-6 30 5943×1850×1400 7770 MQG(Y)1224 ф 200×2400 35.1 4.0 ≤20 1.6〜4.1 Y280S-8 37 5540×2300×1850 10020 MQG(Y)1228 ф 1200×2800 35.1 4.6 ≤20 1.9〜4.8 Y280M-8 45 5940×2300×1850 10935 MQG (Y) 1232 ф 1200×3200 35.1 5.3 ≤20 2.2〜5.5 Y280M-8 45 6340×2300×1850 11230 MQG(Y)1244 ф 1200×4400 35.1 7.3 ≤20 3.0〜7.5 Y135S-8 55 7540 × 2300×1850 13210 MQG(Y)1324 ф 1300×2400 30.2 4.5 ≤20 1.5〜3.5 Y280S-8 37 5035×2370×1880 10210 MQG(Y) 1328 ф 1300×2800 30.2 5.2 ≤20 2.0〜4.5 Y280M-8 45 5435×2370×1880 11290 MQG(Y) 1334 ф 1300×3400 30.2 6.5 ≤20 2.2〜5.0 Y315S-8 55 6035×2370×1880 13117 MQG(Y) 1524 ф 1500×2400 30.7 7.0 ≤20 2.8〜6.5 Y315S-8 55 6830×2930×2060 15430 MQG(Y)1530 ф 1500×3000 30.7 9.0 ≤20 3.5〜8.0 JR117-8 80 7430×2930×2060 16843 MQG(Y)1533 ф 1500×3300 30.7 10.0 ≤20 4.0〜9.0 JR125-8 95 7730×2930×2060 17849 MQG(Y)1536 ф 1500×3600 30.7 11.0 ≤20 4.5〜10.0 JR125-8 95 8030×2930×2060 18649 MQG(Y)1542 ф 1500×4200 30.7 12.5 ≤20 5.0〜11.0 JR126-8 110 8630×2930×2060 19330 MQG(Y)1545 ф 1500×4500 30.7 13.5 ≤20 5.5- 13.5 JR126-8 110 8930×2930×2060 20000 MQG(Y)1557 ф 1500×5700 30.7 17.0 ≤20 7.0〜15.5 JR127-8 130 10130×2930×2060 23597 MQG(Y)1563 ф 1500×6300 30.7 19.0 ≤20 8.0〜17.0 JR128-8 155 10730×2930×2060 24390 MQG(Y) 1830 ф 1830×3000 25.04 13.0 ≤20 3.0〜17.0 JR127-8 130 9525×3960×2250 29490 MQG(Y)1834 ф 1830×3400 25.04 14.0 ≤20 3.3-20.0 JR128-8 155 9925×3960×2250 30390 MQG1836 ф1830×3600 25.04 15.0 ≤20 4.0-21.5 JR128-8 155 10125×3960×2250 31600 MQG(Y)1840 ф1830×4000 25.04 17.0 ≤20 4.5〜24.0 JR128-8 155 10525×3960×2250 32700 MQG(Y)1842 ф1830×4200 25.04 18.0 ≤20 5.0〜25.0 JR136-8 180 10725×3960×2250 33490 MQG(Y)1844 ф1830×4400 25.04 19.0 ≤20 5.2〜26.0 JR136-8 180 10925×3960×2250 34210 MQG(Y)1852 ф1830×5200 25.04 21.0 ≤20 6.5〜32.5 JR136-8 180 11725×3960×2250 37715 MQG(Y)1864 ф1830×6400 25.04 27.0 ≤20 8.0〜40.0 JR137-8 210 12925×3960×2250 42440 MQG(Y)2122 ф2100×2200 23.8 15.0 ≤20 3.0-22.0 JR127-8 130 7775×4060×3400 38793 MQG(Y)2130 ф2100×3000 23.8 20.0 ≤20 4.0〜30.0 JR136-8 180 8475×4060×3400 41965 MQG(Y)2136 ф2100×3750 23.8 21.0 ≤20 5.0〜37.0 JR137-8 210 9225×4060×3400 44551 MQG(Y)2140 ф2100×4000 23.8 22.0 ≤20 5.2〜39.0 JR138-8 245 9475×4060×3400 46697 MQG(Y)2145 ф2100×4500 23.8 25.0 ≤20 5.6〜42.0 JR138-8 245 9975×4060×3400 49230 MQG(Y)2436 ф2400×3600 23.0 26.6 ≤20 6.5〜82.0 JR1410-8 280 9770×5005×3970 63684 MQG (Y) 2444 ф2400×4400 23.0 32.5 ≤20 8.0-100 JR158-8 380 10570×5005×3970 72284 MQG(Y)2736 ф2700×3600 21.7 34.0 ≤20 15.0- 115 JR1512-8 420 10575×5610×4500 88400 MQG(Y)2745 ф2700×4500 21.7 40.0 ≤20 17.5-135 JR1512-8 475 11175×5610×4500 90420 MQG(Y)3230 ф3200×3000 18.7 44.0 ≤20 50.0〜90 TDMK500-36 500 11000×7200×5700 124000 MQG(Y)3245 ф3200×4500 18.7 65.0 ≤20 95〜110 TDMK800-36 800 13000×7200×5700 145000 MQY3254 ф3200×5400 18.7 72 ≤20 96〜140 TDMK1000-36 1000 14155×7200×5700 159600 MQG(Y)3645 ф3600×4500 17.16 87 ≤20 31〜170 TDMK1250-40 1250 15000×7650×6280 185500 MQG(Y)3660 ф3600×6000 17.16 102 ≤20 45〜230 TDMK 1600-40 1600 16750×7700×6530 245000 MQY4060 ф4000×6000 16.8 113 ≤20 According to process conditions TDMK 1500-30 1500 16651×8575×7420 258000
