1,Feed port size
600mm×900mm (width×length)
2.Maximum feed size
≤500mm (adjusted according to material hardness)
3.Adjustment range of discharge port
50-150mm (adjustable, corresponding to different discharge particle size requirements)
4.Processing power
80-200 tons/hour (depending on material characteristics, discharge opening size, etc.)
5.Motor power
75-90kW (usually 4-pole motor, the specific model depends on the configuration)
6.Eccentric shaft speed
250-300r/min (affects crushing efficiency)
7.Equipment weight
About 12-15 tons (including motor and basic frame)
8.Main structural features
Welded frame, made of high-strength steel plate
Hydraulic adjustment of discharge opening (supported by some models)
Deep cavity crushing design to optimize crushing ratio
9.Applicable materials
Granite, basalt, limestone and other medium and high hardness ores
Precautions
The above parameters are general references. Actual performance may vary depending on material humidity, hardness, installation method, etc.
Changes in formula etc.
It is recommended to contact suppliers (such as Shaorui Heavy Industry, Sandvik, or other domestic manufacturers) to obtain
Get the latest technical manual.
The key wearing parts (jaw plate, side guard plate) are usually made of high manganese steel or wear-resistant alloy.
Regular maintenance.
If need more detailed information on motor model, hydraulic system configuration or environmental standards (such as noise, dust emission), please provide specific needs for further supplement.
