1.Especificaciones básicas
Specifications and models:
LT: vertical stirring tank (L vertical, T detoxification/ treatment)
6.5×7.0: tank diameter 6.5m × height 7.0m (effective volume about 230m³)
Type: mechanical stirring detoxification tank (continuous/intermittent operation)
Design standard: HG/T 20569-2013 (chemical stirring equipment)
2.Mixing system
| parámetro | Data |
| Stirrer type | Three bladed inclined propeller/turbine type (low shear) |
| Motor Power | 45-75kW (variable frequency control) |
| speed range | 50-120r/min (adjustable) |
| material | 316L stainless steel/titanium alloy (corrosion-resistant) |
3.Structure design
Tank material:
Standard type: 316L stainless steel (=810mm)
Corrosion-resistant type: carbon steel lined PO/ PTFE (resistant to strong acid and cyanide)
Sealing system: Double-end mechanical seal (leakage ≤5ml/h)
Nitrogen protection interface (explosion-proof design)
Auxiliary functions:
Jacket heating/ cooling (temperature range 20-120℃)
pH/ORP online monitoring (interlock control of dosing)
4.Process performance
Processing capacity:
Liquid flow rate: 100-200m³/h
Solid-liquid mixing: solid content ≤20% (anti-precipitation design required)
Detoxification efficiency:
cyanide degradation rate ≥99.9% (with oxidant)
Reaction time: 2-4h (adjusted according to concentration)
5. Safety and environmental
protection explosion-proof level: Ex dⅡ BT4 (optional)
Waste gas
treatment: The top exhaust port is connected to the alkali liquid absorption tower (to treat HCN)
Protection level: IP65 (outdoor dust and water proof)
6. Equipment size and weight
| parámetro | value |
| Overall height | ≈ 8500mm (including motor) |
| diameter | 6500mm |
| weight | 18-25t |
7. Selection recommendations
1. Highly corrosive conditions (such as cyanide-containing wastewater): choose titanium alloy stirring system + PTFE lining.
2. High temperature detoxification (≥80℃): need to be equipped with high temperature resistant seal and cooling jacket.
3.Maintenance points:
Check the seal and stirring shaft vibration every week
and calibrate the monitoring instrument every quarter
.(Note: The actual selection requires the medium composition, concentration and treatment scale and other parameters.)
